Water Treatment Plant

Ultra Filtration

Images

Ultrafiltration (UF) is a membrane filtration process similar to Reverse Osmosis, using hydrostatic pressure to force water through a semi-permeable membrane. The pore size of the ultrafiltration membrane is usually 103 - 106 Daltons. Ultrafiltration (UF) is a pressure-driven barrier to suspended solids, bacteria, viruses, endotoxins and other pathogens to produce water with very high purity and low silt density.

Ultrafiltration (UF) is a variety of membrane filtration in which hydrostatic pressure forces a liquid against a semi permeable membrane. Suspended solids and solutes of high molecular weight are retained, while water and low molecular weight solutes pass through the membrane. Ultrafiltration is not fundamentally different from reverse osmosis, microfiltration or nanofiltration, except in terms of the size of the molecules it retains. Ultrafiltration (UF) is used to remove essentially all colloidal particles (0.01 to 1.0 microns) from water and some of the largest dissolved contaminants. The pore size in a UF membrane is mainly responsible for determining the type and size of contaminants removed. In general, membrane pores range in size from 0.005 to 0.1 micron.

Benefits
  • No need for chemicals (coagulants, flocculates, disinfectants, pH adjustment)
  • Size-exclusion filtration as opposed to media depth filtration
  • Good and constant quality of the treated water in terms of particle and microbial removal
  • Process and plant compactness
  • Simple automation
  • Environmently friendly
What does ultrafiltration remove?
  • Endotoxins
  • Plastics
  • Proteins
  • Silica
  • Silt
  • Smog
  • Viruses
